Overhead Pneumatic Manipulator | Suspended Truss Handling System | Ergonomic Industrial Robot Arm | Customized Material Handling Solution
The overhead manipulator combines truss rail movement, pneumatic balancing technology, and customized gripping devices to provide a flexible handling solution for automotive manufacturing, machinery production, metal fabrication, assembly lines, and warehouse operations. It is an ideal replacement for repetitive manual lifting tasks and helps create safer, smarter, and more efficient workplaces.
Customized Truss Overhead Crane | Aluminum Rail Lifting System | Vacuum Panel Lifter | Ergonomic Material Handling Equipment | Industrial Handling Solution
The modular truss crane system combines overhead rail technology with vacuum lifting or customized gripping devices, providing an efficient solution for factories requiring frequent lifting, positioning, and transferring of heavy materials. It is widely used in automotive, metal fabrication, glass processing, woodworking, packaging, and general manufacturing industries.
Rated Load Capacity ： 100 kg
Working Radius ： 2500–4000 mm (customizable)
Max Lifting Height ： 2500–3500 mm (customizable)
Control System ： Pneumatic balance control / mechanical handle control
Rotation Range ： 0–360° (optional limit or full rotation)
Tilt Angle ： -90° to +90°
Gripper Type ： External clamping gripper for battery tray (customized available)
Air Pressure Requirement ： 0.6–0.8 MPa
Air Supply ： Clean and dry compressed air
Operating Speed ： Adjustable (stepless control)
Operation Mode ： Single-operator handling
Structure Type ： Column-mounted / cantilever type (optional)
Rotation Mechanism ： Heavy-duty slewing bearing system
Safety Features ： Anti-drop protection / overload protection / emergency stop
Application Industry ： EV battery production / new energy factories / assembly lines
Surface Treatment ： Industrial anti-corrosion coating
Customization : Load capacity, working range, gripper, rotation angle available
Gripper Design : Vacuum, Mechanical Clamp, Magnetic, Combined Type
Load Capacity :50kg–500kg Customized
Arm Structure :Rigid Arm, Articulated Arm, Overhead Type
Rotation Function : 90°, 180°, 270°, 360°
Vacuum System : Vacuum Pump or Venturi Vacuum Generator
Surface Protection : Non-Marking Pads for Sensitive Components
Control Handle : Standard or Ergonomic Customized Handle
Load Capacity : 150 kg
Drive Type : Pneumatic
Working Radius : Customizable according to layout
Lifting Stroke : Customizable for different heights
Rotation Angle : 360° continuous rotation
Control Mode : Manual handle with pneumatic assistance
Fixture Type : Customized clamp / gripper
Installation Type : Floor-mounted column structure
Air Pressure : 0.6 – 0.8 MPa
Application : Loading, unloading, transfer, assembly
Product Name : Roll Film Gantry Crane
Load Capacity : 1500 kg
Lifting Mechanism : Electric hoist
Lifting Height : 2000–3500 mm (customizable)
Span Width : 2000–4000 mm (customizable)
Material : High-strength steel
Control : Remote control / wired control
Mobility : Mobile base with heavy-duty wheels
Power Supply : 220V / 380V / 50Hz (optional)
Lifting Speed : 3–8 m/min
Surface Finish : Anti-corrosion coating
Material Type : Film rolls, paper rolls, plastic rolls
Load Capacity : 250 kg
Crane Type : Truss Type Overhead Crane
Lifting Equipment : Electric Hoist
Span : 3–6 meters (customizable)
Lifting Height : 3–6 meters
Lifting Speed : 4–8 m/min
Hoist Traveling Speed : 10–20 m/min
Power Supply : 220V / 380V
Control Method : Pendant control
Structure Material : High-strength steel truss
Surface Treatment : Powder coating
Application : Light-duty material lifting
Load Capacity : 50 kg
Equipment Type : Mini Pneumatic Robot Arm
Rotation Function : 360° manual rotation
Working Radius : 2–2.5 meters
Lifting Stroke : 1.5 meters
Control Method : Ergonomic handle control
Air Pressure : 0.6–0.8 MPa
Installation Type : Column mounted / Jib crane mounted
Gripper Type : Cylindrical bar clamp
Structure Material : High-strength steel
Surface Treatment : Industrial powder coating
Application : Cylindrical bar and rod handling
The 150kg External Clamp Pneumatic Manipulator is a professional material handling robot arm developed for high-frequency battery lifting, transfer, and precise placement.
It enables operators to handle heavy batteries in a controlled and balanced manner, replacing manual lifting and reducing dependence on traditional hoists or forklifts.
By using pneumatic power assistance and a stable external clamping structure, the manipulator delivers smooth movement, reliable gripping, and accurate positioning. It is designed for production environments where safety, repeatability, and operator comfort are critical.
The 300kg Pneumatic Robotic Arm Lifter with External Grippers for Cylinder Bar Handling is a power-assisted handling device designed for repetitive lifting and positioning of heavy cylindrical workpieces.
It is intended to replace manual handling and conventional hoisting methods in applications where controlled movement, stability, and operator safety are critical.
The Heavy-Duty 150kg Mobile Pneumatic Manipulator with External Clamp for Battery Handling is a power-assisted handling system designed to safely manage heavy battery lifting and positioning tasks.
The system integrates a pneumatic balancing robot arm, a mobile support structure, and a dedicated external clamping tool, enabling controlled movement of batteries throughout the handling process.
The 80kg Mobile Cantilever Crane with Hoist and Replaceable External Clamping Fixtures is designed to address frequent handling changes, limited workspace, and operator safety challenges in industrial environments.
Instead of relying on fixed lifting tools, this system offers a mobile, reconfigurable solution that adapts quickly to different loads and workflows.
By combining a mobile cantilever structure, a stable lifting hoist, and a quick-change external clamping interface, the crane allows operators to lift, transfer, and position materials smoothly and safely. One system can support multiple handling tasks simply by changing the clamping fixtures, making it an efficient alternative to multiple dedicated lifting devices.
250kg Industrial Pneumatic Manipulator with External Clamp for Water Bucket Handling is designed for safe and efficient lifting, gripping, and transferring of heavy water buckets. Featuring a pneumatic balance system and external clamping gripper, it enables smooth vertical and horizontal movement, precise positioning, and low-effort operation, effectively reducing labor intensity and improving workplace safety and productivity.
The 50kg External Clamping Handling Robot Arm for Assembling Circular Rings is a specialized ergonomic handling solution designed for lifting, positioning, and assembling circular metal rings. Featuring a customized external clamping gripper, the system ensures firm and damage-free gripping of circular workpieces during assembly operations.
The Ergonomic 150kg Roll Film Lifting Robot Arm is a customized material handling solution designed specifically for heavy roll film lifting, positioning, and packing operations. Engineered with ergonomic principles, this robot arm enables operators to handle roll films weighing up to 150kg with minimal physical effort, significantly reducing labor intensity and workplace injury risks.
Product Type: Large suction crane
Working Stroke: 0-2000mm or customized
Working Load: 50-2500kg
Fixture Tooling: Suciton pad
Application:Sheet metal, glass plate, wood board
After-sales Service: Video technical support, online support
Warranty: 1 Year
Lead time: 30-50 days
Lifting Capacity : 250 kg
Lifting Height : 2.5 – 3.2 m (customizable)
Arm Length : 1.5 – 2.5 m adjustable
Rotation Angle : 180° – 270° (manual or electric optional)
Power Supply : AC 220V / 380V or pneumatic type
Traveling Type : Manual or motorized wheels
Material : High-strength steel with powder coating
Forklift Base Type : Integrated movable forklift design for easy transport
Surface Treatment : Anti-rust, industrial-grade coating
Control Mode : Handle or button control
Product Name : Industrial Robot Arm Suction Cup Power-assisted Manipulator
Lifting Capacity : 50kg – 300kg (customizable)
Arm Rotation : 0° – 360°
Arm Movement Range : Up/Down, Forward/Backward, Left/Right
Suction Cup Material : High-strength rubber / silicone
Number of Suction Cups : 2 – 8 (customized)
Power Supply : Pneumatic / Electric
Control Mode : Handle Control + Safety Switch
Application: Materials Glass, sheet metal, panels, stone, wood
Installation Type : Column-mounted / Mobile / Overhead Rail
Max Load Capacity: 50 kg
Arm Reach: typically up to 2 meters.
Operating Environment: Suitable for indoor environments such as factories, warehouses, and logistics centers.
Power Source: Pneumatic (Compressed Air)
Operating Pressure: Typically 5-7 bar (adjustable based on system requirements).
Control System: Manual control
Safety Features: Overload protection, emergency stop, anti-collision sensors, and more.
Power Source : Compressed Air (0.5-0.8 MPa)
Load Capacity : Up to 100 kg
Suction Cup : Diameter 50 mm to 300 mm
Arm Length : 1.5 m to 3 m (adjustable)
Vertical Stroke : Up to 2 m
Rotation Angle : 360° (continuous)
Control System : Pneumatic Control Valve
Material : Aluminum Alloy / Stainless Steel
Installation : Floor-mounted Column
Working Temperature : -10°C to 50°C
Product Type: Vacuum lifter
Working Stroke: 100-1800mm or customized
Working Load: 15-300kg
Fixture Tooling: Suciton pad
Application:Bag,sack
After-sales Service: Video Technical Support, Oneline Support
Warranty: 1 Year
Lead time: 30-50 days
Product Type: Vacuum lifter
Working Stroke: 100-1800mm or customized
Working Load: 15-300kg
Fixture Tooling: Suciton pad
Application:Rubber Blocks, Baggages,Boxes,Bags
After-sales Service: Video Technical Support, Oneline Support
Warranty: 1 Year
Lead time: 30-50 days
Product Name : Pneumatic Assisted Robotic Arm Manipulator
Lifting Capacity : 50–500 kg (customizable up to 800 kg)
Maximum Arm Reach : 2000–4000 mm
Vertical Lifting Stroke : 1200–2500 mm
Air Supply Requirement : 0.6–0.8 MPa
Fixture Type : Customized clamp / mandrel / suction cup
Rotation : 0–360° horizontal & vertical rotation
Mounting Options : Floor-mounted / Overhead / Rail-mounted
Control Method : Pneumatic handle with safety interlock
Safety System : Overload protection, anti-drop device
Main features:
1. High load-bearing capacity: 500kg, which is suitable for the handling of heavy materials and components.
2. Permanent magnetic lifter: Use permanent magnetic system ensuring safety and reliability.
3. Pneumatic operation: driven by a pneumatic system, lifting and lowering actions are fast and flexible, and the response is fast.
4. Multi-spindle design: improves flexibility, can handle multiple items or provide different gripping options, and adapts to various application needs.
5. Customized fixtures: customized fixtures can be designed according to user needs to ensure optimal performance and safety, and adapt to materials of different shapes and sizes.
6. Durability and maintenance: made of high-quality materials, durable and simple to maintain, it is an economical solution for long-term use.
7. Safety features: equipped with overload protection and emergency stop functions to ensure the safety of the handling process.
Application areas:
- Metal processing and machinery manufacturing
- Assembly line
- Warehousing and logistics
- Heavy equipment handling
- Shipbuilding and construction
Load Capacity : Up to 50kg
Gripping Method : Electric
Working Range : 1000mm
Speed : Up to 20 items per minute
Power Supply : AC 220V 50Hz, Power: 3kW
Control System : PLC Control + Vision Recognition System
Operating Temperature : -10°C to 40°C
Safety Features : Mechanical guard, emergency stop button, collision detection, and obstacle avoidance features
Power Source : Compressed Air (0.6–0.8 MPa)
Lifting Capacity : 50 kg – 800 kg (customizable up to 1000+ kg)
Gripping Method : Vacuum suction cups
Suction Cup Material : High-quality rubber / silicone (optional heat-resistant type)
Number of Suction Cups : Customizable based on plate size
Working Radius : 1.5 – 3.5 meters (customizable)
Lifting Stroke : 0 – 2 meters
Structure Material : High-strength carbon steel / aluminum alloy
Rotation Function : Optional 0–360° rotation & 90° tilting
Safety Features : Anti-drop check valve, vacuum loss alarm, pressure monitoring
Lifting Capacity : 500 kg
Suction Cup Diameter : 250 mm / Customizable
Number of Suction Cups : 4–8 (Adjustable according to load)
Frame Type : Fixed or Rotating Frame
Rotation : 0°–360° Manual / Electric
Tilting Function : 0°–90° Manual / Electric
Power Source : Electric or Pneumatic Vacuum Pump
Safety Features : Vacuum Pressure Gauge, Alarm, Check Valve
Type : Wall Mounted Vacuum Tube Lifter
Max Lifting Capacity : 500 kg (Customizable upon request)
Lifting Height Range : 1.5m – 3.0m (adjustable)
Power Supply : 220V / 50Hz / 1 Phase
Vacuum System : Electric Vacuum Pump (High Efficiency)
Control System : Handlebar Control with Integrated Buttons
Suction Cup Material : Nitrile Rubber / Silicone (customizable)
Operating Temperature : -10°C to 40°C
Mounting Type : Wall Mounted (Flexible installation)
Application : Bags, Cartons, Small Pallets, Light Materials
The 25kg Box Vacuum Lifter is a compact, efficient lifting device designed for fast and ergonomic handling of cardboard boxes, cartons, and light packages. Powered by vacuum suction, this equipment greatly reduces manual effort and the risk of repetitive strain injuries, making it ideal for packaging lines, warehouses, and logistics centers.
The 0.5 Ton Portable Mobile Arm Jib Crane is a compact, movable lifting system ideal for flexible and on-demand material handling. Unlike traditional fixed jib cranes, this model is mounted on a wheeled base with an integrated pillar, allowing it to be moved effortlessly between workstations. It's the perfect solution for workshops, warehouses, and assembly lines where flexibility and space optimization are key.
The 180° Rotating 500kg Swing Arm Traveling Cantilever Jib Crane is a versatile material lifting solution designed for efficient handling along production lines, assembly areas, or workstations. Mounted on a linear rail, this cantilever crane allows the arm to travel horizontally along the track while providing a 180-degree rotational range for flexible coverage. With a robust 500kg lifting capacity and compatibility with electric hoists, it is an ideal solution for repetitive and space-constrained lifting operations.
Product Type: Rigid Arm Manipulator
Working Stroke: 0-3000mm or customized
Working Load: 50-500kg or customized
Fixture Tooling: Mechanical manipulator
Application:Metal profiles,and other regular shape loads
After-sales Service: Video Technical Support, Oneline Support
Warranty: 1 Year
Lead time: 30-50 days
Applicable bag weight : 10-50kg (can be customized according to customer needs)
Palletizing speed : 600-1200 bags/hour (depending on bagging specifications and pallet type)
Robot degrees of freedom : 4-6 axes
Stack maximum height : up to 2.5 meters
Control System : PLC+touch screen, supports multiple communication protocols
Power Requirements : 380V/50Hz (can be customized according to customer needs)
Area : Compact design, saves space
Load Capacity : 50-200kg(Depends on model)
Product Type: Rigid Arm Manipulator
Working Stroke: 0-3000mm or customized
Working Load: 50-300kg or customized
Fixture Tooling: Permanent magnet block adsorption
Application: Regular steel blocks, steel sheets,or steel discs
Lead time: 30-50 days
The intelligent electric lifting manipulator of the column-type cantilever crane is a modern material handling equipment that integrates rotary handling, intelligent control and multi-station operation.
Power Source : Pneumatic
Load Capacity : 500 kg
Arm Reach : 2 meters
Rotational Range : 360° rotation capability
Max Roll Diameter :1500 mm
Max Roll Length : 2000 mm
Grip Mechanism : Vacuum suction or mechanical claw (customizable)
Operating Pressure : 6-8 bar
Control System : Semi-Automatic
Air Consumption : 300-400 L/min
Material of Construction : Stainless Steel
Safety Features : Overload protection, emergency stop button, sensors for safe operation
Weight : 500 kg (customizable)
