SLJ-150E
ESCOTT
Product Description
The Industrial Robot Arm Magnetic Pneumatic Manipulator is a high-performance automation solution designed for the safe, efficient, and contact-free handling of steel materials. By integrating electromagnetic gripping with pneumatic actuation, it provides precise, programmable movement for lifting, positioning, and transferring steel plates, bars, and components in industrial environments.
This manipulator is ideal for replacing manual operations in metalworking, warehousing, and manufacturing, reducing labor intensity and improving safety and productivity.
| Parameter | Specification |
|---|---|
| Payload Capacity | Up to 100 kg (customizable) |
| Manipulator Type | 6-Axis Industrial Robot Arm |
| End Effector | Magnetic Gripper (electromagnetic or permanent) |
| Control System | PLC / CNC / ROS / PC-based |
| Power Supply | 220V / 380V (electric) + compressed air |
| Operating Pressure | 0.4 – 0.6 MPa (for pneumatic control) |
| Rotation Range | 360° (base), full joint articulation |
| Repeatability | ±0.05 mm |
| Mounting Type | Floor or pedestal mount |
| Control Mode | Manual teaching / Programmed / Remote |
| Safety Features | Emergency stop, overload protection, magnetic lock sensor |
Magnetic Gripping – Safe and efficient steel handling without clamping damage
Pneumatic Assistance – Smooth, responsive, and energy-efficient arm motion
Full Automation Ready – Easily integrates into smart factory workflows
High Load Capacity – Handles heavy and large steel sheets or parts
Flexible Programming – Supports various control systems including ROS and PLC
Durable Build – Designed for harsh industrial environments with dust and vibration resistance
Enhanced Safety – Equipped with sensors, alarms, and emergency override options
Steel Sheet and Plate Handling – Loading/unloading in cutting, stamping, and pressing lines
Warehouse Automation – Lifting and stacking of metal parts or bundles
Automotive Manufacturing – Manipulating steel components during welding or assembly
Heavy Machinery Workshops – Moving and aligning structural steel parts
Robotic Palletizing – Automating steel part sorting and placement in logistics systems
