Product Description
The 180° Rotating 500kg Swing Arm Traveling Cantilever Jib Crane is a versatile material lifting solution designed for efficient handling along production lines, assembly areas, or workstations. Mounted on a linear rail, this cantilever crane allows the arm to travel horizontally along the track while providing a 180-degree rotational range for flexible coverage. With a robust 500kg lifting capacity and compatibility with electric hoists, it is an ideal solution for repetitive and space-constrained lifting operations.
|
Product Parameters
| Item | Specification |
| Model | EST-TC500 |
| Maximum Load Capacity | 500 kg |
| Jib Arm Type | Cantilever swing arm |
| Arm Length | 3 m (customizable 2–4 m) |
| Rotation Range | 180° |
| Rail Travel Length | 4–12 m (customizable) |
| Lifting Mechanism | Electric chain hoist / wire rope hoist |
| Lifting Height | Up to 3 m (customizable) |
| Power Supply | 220V / 380V, 50Hz |
| Slewing Mechanism | Manual or electric rotation |
| Travel Mechanism | Manual push or electric motorized trolley |
| Installation | Wall-mounted rail or floor rail + column |
|
Features
1. 180° Slewing Rotation
Provides wide-angle arm coverage for picking and placing materials in semi-circular working areas.
2. Linear Traveling Design
The jib arm is mounted on a rail system that allows horizontal movement across multiple workstations or production bays.
3. High Load Capacity
Safely lifts up to 500kg, suitable for moderate-to-heavy loads such as machinery parts, molds, and pallets.
4. Compatible with Electric Hoists
Works seamlessly with electric chain or wire rope hoists for vertical lifting with speed and safety.
5. Flexible Mounting Options
Available as wall-mounted or track-on-ground models, adapting to your facility's layout and space requirements.
6. Safe and Efficient Operation
Features limit stops, mechanical locking, optional soft start, and overload protection to ensure operator safety and equipment longevity.
handle
fixture
controller
|
Application Scenario
1. Production & Assembly Lines
Perfect for moving components between stations in a linear workflow with limited floor space.
2. Loading & Unloading Areas
Supports loading operations from pallets to trucks or conveyors along long transfer zones.
3. Mechanical Workshops
Lifting and positioning engines, tools, or equipment into precise locations during repair or fabrication.
4. Warehouse & Storage Facilities
Enables movement of heavy cartons, drums, and crates from storage racks to packing stations.
5. Tooling & Molding Applications
Positioning of heavy dies, fixtures, or machine parts during maintenance or assembly processes.
