EST-500M
ESCOTT
Product Description
In many manufacturing industries, operators still face challenges when handling heavy, large, or irregular-shaped components. Repetitive lifting tasks can lead to high labor intensity, low production efficiency, and increased risk of workplace injuries. The 500kg Overhead Truss Pneumatic Manipulator provides an ergonomic and efficient solution by combining an overhead rail system with pneumatic power assistance, allowing operators to move heavy loads with minimal effort.
The ceiling-mounted truss structure maximizes available workspace by eliminating floor obstacles while providing smooth horizontal movement across the working area. The pneumatic manipulator arm offers precise lifting, lowering, positioning, and rotation functions, helping workers complete material transfer operations quickly and safely.
With customized end effectors such as vacuum lifters, mechanical clamps, hooks, or special fixtures, this system can adapt to different products and production processes, making it an ideal handling solution for automotive parts, metal components, machinery parts, molds, panels, boxes, and other industrial materials.
Technical Specifications
| Item | Specification |
|---|---|
| Product Name | Overhead Truss Pneumatic Manipulator |
| Lifting Capacity | 50kg-500kg (Customized) |
| Installation Type | Ceiling Mounted / Suspended |
| Power Source | Compressed Air |
| Working Movement | X/Y Axis Rail Movement |
| Arm Rotation | 90°/180°/360° Optional |
| Control Method | Ergonomic Handle Control |
| Gripper Type | Vacuum Cup / Clamp / Customized Fixture |
| Structure Material | Steel / Aluminum Alloy |
| Application | Industrial Material Handling |
Main Components
The suspended truss structure provides a large working coverage area and flexible movement.
Features:
Ceiling-mounted installation saves floor space
Modular design for different workshop layouts
Smooth and stable movement
Suitable for production line integration
Low maintenance requirements
The pneumatic balancing mechanism provides ergonomic assistance during lifting operations.
Advantages:
Reduces operator physical workload
Enables one-person operation of heavy components
Provides precise positioning control
Improves handling speed and accuracy
Suitable for continuous production environments
ESCOTT designs different gripping tools according to customer products:
Suitable for:
Metal sheets
Glass panels
Plastic plates
Smooth surface materials
Suitable for:
Automotive components
Boxes
Machinery parts
Irregular-shaped products
Designed according to:
Product shape
Weight
Handling direction
Production requirements
Product Features
The pneumatic power-assisted system reduces manual lifting difficulty and allows operators to handle heavy products easily, improving working comfort and reducing fatigue.
Unlike traditional floor-mounted lifting equipment, the suspended installation does not occupy production floor space, making it suitable for compact factories and automated production lines.
The truss rail system provides smooth multi-directional movement, enabling operators to transfer materials between different workstations efficiently.
ESCOTT provides complete customized solutions including lifting capacity, rail dimensions, gripper design, rotation function, and control methods.
By replacing repetitive manual lifting operations, the manipulator helps:
Reduce labor intensity
Increase handling efficiency
Minimize product damage
Improve workplace safety
Application Industries
Engine parts handling
Vehicle component transfer
Assembly line feeding
Battery module handling
Steel plate handling
Aluminum parts transfer
CNC machine loading and unloading
Welding workstation material movement
Heavy component assembly
Mold handling
Equipment parts positioning
Product assembly assistance
Clean workstation handling
Component transfer
Carton handling
Material feeding
Warehouse workstation operations
